Production line dimension (reference) : about 42000mm * 6000mm

Equipment working face height: 900mm from the ground.

Stations :10

Roll forming width range: 370 ~ 650mm

U shell height: 350 ~ 1800 mm

Bending U width: 350 ~ 700mm

Single side plate length: 900 ~ ~ 1800mm

Production takt: no more than 21S/ piece; Product change time is 2 minutes.

Applicable material: cold rolled plate, coated color board (PCM board)

Sheet thickness: 0.50mm

Installed capacity: about 45KVA (380V, 50Hz)

Air supply:0.5-0.65MPa

Water source: industrial tap water

Line body color:specified or according to the color board
